Model

JS6108GHFCEV

Sizes L*W*H（mm）

10500*2500*3470

GVW（kg）

16500

Net weight (kg)

10800

Loading capacity (kg)

5300

Passenger capacity, Seats

80 persons, 24 / 45

Axle capacity (kg)

F:6400, R:10100

Wheel track F/R

F: 2075/ R：1860

Wheel base (mm)

5100

Suspension (mm) F/R

2290/3110(mm)

Approach / departure angle

7/7(°)

Tire

11R22.5,275/70R22.5

Break

Front disk brake and rear drum brake

Max speed（km/h）

69

Power battery

FeLiPO4

Motor power Rated/Peek（kW）

80/160

Fuel

Hydrogen

Power type

Hydrogen-Air proton exchange membrane fuel cell

Motor power model,

TZ370XS08001/ 160kw.

Fuel battery rated power（kW）

46

Motor power system manufacturer

Weichai Power

H2 storage system（35Mpa）

140L*4

Run ranger（km）

≥510
